Flat metallization - maximum variety of substrates

DM-Maxliner 2D



Flat metallization - applied with digital technology to an amazing variety of substrates

The industrial solution for digital sheet-fed application of flat DIGITAL METAL® (2D) on B3 sheet format. This machine combines the Inkjet and sheet-fed know-how of Steinemann DPE and the metallization expertise of KURZ, sets completely new standards in terms of performance and flexibility of digital embellishment.

As a result, our customers can benefit from enormous quality, productivity, efficiency, and versatility on an industrial scale.

Flat metallization effects in DIN B3 size format

Output of up to 3,500 sheets/h with DIGITAL METAL® application

Short set-up times and maximum substrate flexibility

Compact, industrial design for reliability, durability and low maintenance requirements

Assets of the DM-Maxliner 2D

Flexible format sizes

Embellishment of sheet sized from 210 x 297 mm up to 353 x 500 mm



Wide substrate variety

Good processability of many different substrates - even if uncoated



Excellent quality

Look & feel comparable to analog flat hot stamping applications



Industrial speed

Up to 3.500 sheets/h



Enormous efficiency

Extremely low set-up times, quick job changes, no hot stamping tools needed



Highest availability

Industrial components, compact machine design



Professional assistance

System solution with machine, software, consumables and service – everything from a single source



Technical data

Technical data of DM-Maxliner 2D

SubstrateSI UnitsU.S. Units
Sheet size max. (width x length)355 x 508 mm14 x 20 in
Sheet size min. (width x length)210 x 297 mm8.27 x 11.7 in
Sheet weight 225 - 450 g/m2225 - 450 g/m2
Sheet thickness0.08 - 0.5 mm
Performance
Working speed*10 - 35 m/min32.8 - 114.8 fpm
 3500 sheets/h
Native resolution600 dpi600 dpi
Lay down1.7 – 12.6 g/m²1.7 – 12.6 g/m²
Register accuracy+/- 0.3 mm+/- 0.012 in
Print dataPDF (Standard), BMP, TIFF, ...
Transfer metallizationKURZ DIGITAL METAL® DT-S
Glue typespecial UV inkjet glue
Maschine dimensions (length x height x width)4.8 x 1.9 x 2.1 m15.8 x 6.2 x 6.9 ft



* Depending on sheet size, in-house conditions, sheet humidity, used substrates and sheet weight. All technical data represent approximation values. Steinemann DPE reserves the right to make mechanical and design modifications.
